SKU: PROSquare3 Pendant

PROSquare3 Pendant is a 3×3" pendant linear LED delivering 1,500 lm/ft at 150 lm/W with SmartBeam® optics for symmetric and asymmetric distributions. It supports direct and indirect light with multiple integral driver and mounting kit options.


View our BAA/BABA Compliance page to learn about about how we can support making your project or product compliant.

QUICK SPECS

    PROSquare3 Pendant brings SmartBeam® capabilities to a 3” form factor with an integral driver providing best-in-class efficiency and beam control options. The PROSquare3 Pendant is designed to be specification grade with a wide range of beam options, high CRI, and circadian options. The 3″ aperture delivers comfortable illumination in a wide range of beam distributions while achieving high efficacy, and energy-saving performance. PROSquare3 Ppendant can be supplied with a range of integral driver options and mounting kits for drywall panel and T-Bar ceiling grid mounting. Choice of finishes and colors provide an easy route to customization and performance enhancements.

    Features

    • 3″ aperture
    • 1,500 lm/ft, 150 lm/W efficacy
    • Install onto drywall or grid t-Bar
    • Field serviceable driver, LED engine and optics
    • Supports direct & indirect light
    • Symmetric and asymmetric beam distributions
    • BABAA compliant, designed and manufactured in America

    Details

    Parameter Specification
    Dimensions 3” (W) X 3” (H)
    Mounting Style Drywall or Grid T-Bar
    Standard Lengths 2’, 4’, 6’, 8’, & Continuous Runs
    Finishes Powder Coated & Anodized
    Housing Material Extruded, Recycled Aluminum
    Warranty 5-Year Warranty
    Sustainability Declare Listed & Red List Free
    LED Performance 1,500 lm/ft, 150 lm/W Efficacy
    LED Choices Static White & Tunable White
    Optics Choices Flush Lens & Regressed Lens
    CRI / CCT 80/90/95+, 2700K to 6500K
    Driver Options Factory, Lutron & eldoLED
    Emergency Backup Emergency Circuit & Battery
    Compatible Controls Lutron, Casambi, Cooper, nLight
    Power Cord 48” & 96”
